UsingtheRouter’sWebInterface 31

Definingtunnelstoyourdevice
SettingupGeneric RoutingEncapsulation(GRE)tunnels
Tunnelingallowstheuseofapublicnetworktoconveydataonbehalfoftworemoteprivatenetworks.Itis
alsoawaytotransformdataframestoallowthemtopassnetworkswithincompatibleaddressspacesoreven
incompatibleprotocols.
GenericRoutingEncapsulation(GRE)isatunnelingmechanismthatusesIPasthetrans
p
ortprotocolandcan
beusedforcarryingmanydifferentpassengerprotocols.Thetunnelsbehaveasvirtualpoint‐to‐pointlinks
thathavetwoendpointsidentifiedbythetunnelsourceandtunneldestinationaddressesateachendpoint.
ConfiguringaGREtunnelinvolvescreatingatunnelinterface,whichisalogicalinterface,thenconfi
g
uringthe
tunnelendpointsforthetunnelinterface.
TosetupGREtunnels:
1. FromTunnels,selectGRETunnels.TheTunnels:GRETunnelspaneopens.
2. FromtheTunnels:GRETunnelspane,clickAddTunnel.
Aseriesofwizardpanelshelpsyouconfiguretheconnection.
3. IntheTu
nn
elNamefield,enteranameforthenewtunnel.
4. Inthedescriptionarea,typeadescriptionthathelpsyoufurtheridentifythetunnel.ClickNext.
5. Inthenextwizardpane:
 IntheRemoteWANIPfield,typetheIPaddressofthegatewaytowhichyouwanttoconnect.
 (Optional)FromtheSavedNetworkdrop‐downlist,selectthenetworkthatistoberoutedthrough
thetunnel.Toselectalocalinterface:Selectthelocalinterfaceonwhichthetunnelisbeingcreated.
Eventually,thepacketsdestinedforthistunnelwillberoutedthroughit
 Ifyouarenotusingasavednetwork,intheNetworkRoutefield,typetheIPaddressofthenetwork
thatisroutedthroughthetunnel.
 Ifyouarenotusingasavednetwork,intheNetworkMaskfield,typethemaskofthenetwork.
 ClickAddRoute.ThedefinedGREtunnelconfigurationisaddedandappearsintheNetworkRoutes
list.
6. ClickFinish.
