UsingtheRouter’sWebInterface 23



8. IntheSourcePortfield,typetheportthatistheoriginofthetraffic.TypeANYifthesourceportdoes

notmatter.

9. FromtheActiondrop‐downlist,selecttheactiontoperformonthetraffic.Youcanallowthetrafficto

beaccepted,rejected,loggedordroppe

d.Ac

ceptedpacketsareallowedtocontinuethroughthe

firewall.Droppedpacketsareremovedandnofurtherprocessingisperformedonthem.Rejected

packetsaredropped,andanerrormessageissenttothesourceofthepacket.Loggedpacketsare

loggedtothesystem'smainlogfilewiththerule'snamepr

epended

asanidentifier(viewablefromthe

Statisticspage).Logrulesdonotaffectthepacket'sfate.

10. TheDirectionislockedtoOUTGOINGwhileusingtheOutboundTrafficwizard.

11. FromtheProtocoldrop‐downlist,selecttheprotocolofthetrafficthatisbeingfiltered.

AdvancedSettings 

TheFirewall'sAdvancedSettingsmodeallowsuserstomanipulateDNAT,SNAT,andFilterrulesdirectly.DNAT

rulescanmanipulatethedestinationaddressandportofapacket;similarlySNATrulescanmanipulatethe

sourceaddressandportofapacket.

FilterrulesapplyanACCEPT,REJECT,DROP,orLOGactiontoapack

et.DN

AT,SNAT,andFilterrulescanbe

associatediftheyarenamedthesame.ThisassociationisrecognizedwithinthePortForwardingand

OutboundTrafficwizardsaccessedfromtheNormalSettingsmode,andallowstheassociatedrulestobe

viewedandeditedasaseries.

Settingupstaticroutes

TosetupamanuallyconfiguredmappingofanIPaddresstoanext‐hopdestinationfordatapackets:

1. FromFirewall,selectStaticRoutes.

2. Inthepanethatappears,clickAddRoute.

3. IntheNamefield,typethenameoftheroute.

4. IntheAddressfield,typetheremotenetwo

kIPaddressoftheremotelocation.

5. IntheMaskfield,typethenetworkmaskthatisassignedontheremotelocation.

6. IntheGatewayfield,typetheIPaddressoftheroutingdevicethatsupportstheremoteIPNetwork.

7. ClickFinish.
