Murr Elektronik Data Panel xtreme DB DP-34044-1 User Manual

46
PGN
65301(0xFF15)E0=SA
Source Address
224(0xE0)
PDU Format
255(0xFF)
PDU Specic
21(0x15)
Built Message
(0x18FF15E0)
J1939DigitalStatus
Name Data Type Byte Bits Description
Input1A
2 bit
1
1,2
NotUsed
Input1B 3,4
Input2A 5,6
Input2B 7,8
Input3A
2
1,2
Input3B 3,4
Input4A 5,6
Input4B 7,8
Input5A
3
1,2
00=O,01=On,10=Fault
Input5B 3,4
Input6A 5,6
Input6B 7,8
Input7A
4
1,2
Input7B 3,4
Input8A 5,6
Input8B 7,8
Notused Byte
5
6
7
8
Transmit rate
50 ms
Msg timeout
200 ms
Priority
6
DP
0
