PGN
65304(0xFF18)
Source Address
224(0xE0)
PDU Format
255(0xFF)
PDU Specic
24(0x18)
Built Message
(0x18FF18E0)
J1939AnalogStatus1
Name Data Type Byte Bits Description
Analog Input 5A Word 1 Low Byte Not Used on this module, discrete only
2 HighByte
Analog Input 5B Word 3 Low Byte
AnalogInput5B,(4-20ma=4,000-20,000)(0-5VDC=0-5,000mv)(0-10VDC=0-10,000mv)
(0-32VDC=0-32,000mv)(Ratiometric=0-100.0%ofsourcevoltage)
4 HighByte
AnalogInput6A Word 5 Low Byte Not Used on this module, discrete only
6 HighByte
AnalogInput6B Word 7 Low Byte
AnalogInput6B,(4-20ma=4,000-20,000)(0-5VDC=0-5,000mv)(0-10VDC=0-10,000mv)
(0-32VDC=0-32,000mv)(Ratiometric=0-100.0%ofsourcevoltage)
8 HighByte
PGN
65305(0xFF19)
Source Address
224(0xE0)
PDU Format
255(0xFF)
PDU Specic
25(0x19)
Built Message
(0x18FF19E0)
Transmit rate
50 ms
Msg timeout
200 ms
Priority
24(0x18)
J1939AnalogStatus2
Name Data Type Byte Bits Description
AnalogInput7A Word 1 Low Byte Not Used on this module, discrete only
2 HighByte
AnalogInput7B Word 3 Low Byte
AnalogInput7B,(4-20ma=4,000-20,000)(0-5VDC=0-5,000mv)(0-10VDC=0-10,000mv)
(0-32VDC=0-32,000mv)(Ratiometric=0-100.0%ofsourcevoltage)
4 HighByte
AnalogInput8A Word 5 Low Byte Not Used on this module, discrete only
6 HighByte
AnalogInput8B Word 7 Low Byte
AnalogInput8B,(4-20ma=4,000-20,000)(0-5VDC=0-5,000mv)(0-10VDC=0-10,000mv)
(0-32VDC=0-32,000mv)(Ratiometric=0-100.0%ofsourcevoltage)
8 HighByte
Transmit rate
50 ms
Msg timeout
200 ms
Priority
6
DP
