Manual MVK-MP
V 3.5 35
4.3.5.2. Data Format MVK AI4(U) Art.-No. 55293
Representation of analog values of input data 15 Bit.
Measuring range
0..10 V
Measuring value
Rang
Diagnostics
binary
hexadecimal
decimal
>10 V
0111 1111 1111 1111
7FFF
32767
Over range
yes
10 V
5V
0,0003mV
0
0111 1111 1111 1111
0011 1111 1111 1111
0000 0000 0000 0001
0000 0000 0000 0000
7FFF
3FFF
0001
0000
32767
16383
1
0
Nominal range -
< 0V
0000 0000 0000 0000
0000
0
Under range
-
Tab. 10: Analog values MVK AI4(U) Art.-No. 55293 in the range of 0...10 V
Representation of analog values of input data 15 Bit.
Measuring range
2..10 V
Measuring value
Range
Diagnostics
binary
hexadecimal
decimal
>10 V
0111 1111 1111 1111
7FFF
32767
Over range
yes
10 V
6V
2,0002V
2V
0111 1111 1111 1111
0011 1111 1111 1111
0000 0000 0000 0001
0000 0000 0000 0000
7FFF
3FFF
0001
0000
32767
16383
1
0
Nominal range -
< 0V
0000 0000 0000 0000
0000
0
Under range
-
Tab. 11: Analog values MVK AI4(U) Art.-No. 55293 in the range of 2...10 V
