4.4.1 How to code functions with more than two options
For several parameters, more than two options are possible. Each of these parameters is coded with
two bits. Values from 0
dez
to 3
dez
are therefore possible. Please note that the coding of the functions of
Pin 2 and Pin 4 is not identical.
4.4.2 Parameterization of the General Diagnostic Messages
Modules
Description
Decimal
Bit 0
AO4 (I) DIO4 (DIO4)
Art.-No. 55292
AI4 (U) DIO4 (DIO4)
Art.-No. 55293
Diagnostic messages
Release global diagnostic
0
Do not release global diagnostic
1
Channel diagnostic
Report
0
Do not report
1
Under voltage bus /
sensor supply
Report
0
Do not report
1
Under voltage
aktuator supply
Report
0
Do not report
1
No Aktuator supply
Report
0
Do not report
1
Tab. 12: Parameterization of the general diagnostic messages
4.4.3 Parameterization of the Data Format
Modules
Description
Decimal
Bit 0
AO4 (I) DIO4 (DIO4)
Art.-No. 55292
AI4 (U) DIO4 (DIO4)
Art.-No. 55293
Data format
byte sequence high/low (Motorola)
0
byte sequence low/high (Intel)
1
Tab. 13: Parameterization of the Data Format
4.4.4 Parameterization of Smoothing (AI4 (U) DIO4 (DIO4) Art.-No. 55293)
Module
Description
Value
Bit 0
Bit 1
AI4 (U) DIO4 (DIO4)
Art.-No. 55293
Smoothing
none
0
0
weak
0
1
moderate
1
0
strong
1
1
Tab. 14: Parameterization of Smoothing
4.4.5 Parameterization Functionality of Channels 00 to 07 (Pin 4)
Modules
Description
Decimal
Bit 1
Bit 0
DO4(DO4) DI4(DI4)
Art.-No. 55274
only channels 4 to 7
Normally open input
0
0
0
Normally closed input
1
0
1
