Manual MVK-MP
V 3.5 51
5.3.3 ID-related diagnostic bytes 8 to 9
Byte 8 ID-related diagnostic - header byte
7
6
5
4
3
2
1
0
Block length in bytes, incl. header byte. Here: 02
hex
Reserved for 01
Fig. 41: Byte 8 ID-related diagnostic - header byte
Byte 9 ID-related diagnostic – ID Number
7
6
5
4
3
2
1
0
ID number (MVK-MP set to 01
hex
)
Fig. 42: Byte 9 ID-related diagnostic – ID Number
5.3.4 Byte 10 to 12 and following: Channel-related diagnostic
Three bytes are assigned in the diagnostic message for each channel-related diagnostic. If, for
example, 5 channel-related diagnostics are available, a total of 5 x 3 = 15 bytes channel-related
diagnostic information.
Byte 10 ID number
7
6
5
4
3
2
1
0
ID number 0…63 MVK-MP: 00
hex
Reserved for 10
Fig. 43: Byte 10 ID number
Byte 11 Channel number
7
6
5
4
3
2
1
0
Channel number 0…63
MVK-MP : 00..07(Pin 4) or 10..17(Pin 2)
Input/output
00 = reserved
01 = input
10 = output
11 = input/output
Fig. 44: Byte 11 Channel number
