4.4 Parameterization
The MVK-MP parameter message comprises 19 Bytes. The first 7 bytes are defined by Profibus
standard IEC 50170. The following 12 bytes are user parameter.
The majority of configuration tools divide user parameters into module-related and
station-related parameters that, as a general rule, appear in various dialogs in the
user interface of the configuration tool.
The reserved bytes 0 to 2 of the user parameters are station related parameters on
the MVK-MP.
All necessary settings are made via the module-related parameter starting from
byte 3 of the user parameters. These parameters are always assigned to the virtual
head module.
