Manual MVK-MP
V 3.5 25
3.3.2 Connection of Supply Voltage
Reverse polarity of the power supply can damage the module. Therefore, we
recommend using pre-wired connectors from Murrelektronik.
Connecting Supply Voltage on the Module
The supply of actuators and sensors requires auxiliary power. The electronics of the MVK-MP are
supplied via the sensor supply.
The sensor supply voltage must not be deactivatable. It supplies the power for the
electronics.
The 7/8" plug is designed for a max. current of 9 A per pin. This has to be
considered when looping through the supply voltage.
