Operation Instructions Spitfire 65/90 Extreme
CHAPTER 4 : PERIODICAL MAINTENANCE
37 AP-77140 – Rev. 1.1 – 05/04/07
4 PERIODICAL MAINTENANCE
4.1 DONE BY END USER
This section describes the periodical services required for this machine. The periodical services ensure
stable printout quality of the machine. In the periodical services, some service parts may be checked,
cleaned, or replaced.
Perform periodical inspections according to the table below.
N Action Frequency
1
Clean wipers
2
Flush caps in maintenance station
3
Clean the edges of the caps in maintenance station
Daily maintenance
4
Clean the area around the caps
5
Clean around bottom of the heads
Weekly maintenance
6
Change the wipers
7
Change upper sponge at back of the capping station
Monthly maintenance
8
Replacing the sponge in the spitting box
2 weekly maintenance
Available kits for the end user and their order numbers
1. User and good shape kit for 6 months
KY-80229
No Description Quantity
1
Sponge plate 6
2
Wipers 24
3
Spitting box sponge 12
4
Cleaning Liquid 250 ml 3
5
Instruction sheet 1
6
Good shape kit 1
2. Good shape kit
KY-80228
No Description Quantity
1
Gloves 300
2
Pipette 60
3
Swabs 150
4
Polyknit wiper 300
3. Long store kit KY-80230
No Description Quantity
1
Spitfire Mild Solvent Cleaning Liquid 8
2
Ink kit
Black
Cyan
Magenta
Yellow
2
2
2
2
4. Solvent cleaning in a bottle
T17S250CLN
