hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL
EN
DEVICE INSTALLATION AND CALIBRATION » 3D calibration
4.7 3D CALIBRATION
Required instruments
3D calibration kit, including:
• cylinder with two rows of eight metal spheres (code 97901494)
• support plate
All covers must be assembled.
4.7.1 BEAM LIMITER TEST
