182

STANDBY

X-RAY READY

INTERLOCK

hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL

CONTROL PANELS AND DISPLAY SYMBOLS

5.2 PUSHBUTTON PANEL ON CEPH ARM

COLUMN

UPWARD MOVEMENT

COLUMN

DOWNWARD MOVEMENT
