CIRCUIT BOARDS
7.3.1 CONNECTOR LIST
CONNECTOR DESCRIPTION
K1 Column motor power supply
K2 Column motor thermal sensor
K3 Monoblock High voltage
K4 Power switch live wire
K5 Power switch neutral wire
K7 Gigabit switch power supply
K9 Monobloc feedback
K10 X-ray button (1/2 = Button, 3 = Ready, 4 = X-Ray)
K11 Door interlock
K12 External emergency button
K13 Column upper endpoint photocell
K14 External signal lamps (Wires 1,2 ready - Wires 3,4 X-ray emission)
K15 Machine On-Board Emergency Access
K16 LOGIC-board power supply
K17 Mains power supply
K18 Column lower endpoint photocell
K21 CAN towards LOGIC or BRUSHDC
K22 Column anti-pinch switch
7.3.2 DIAGNOSTIC LEDS
NAME COLOUR SCREEN PRINTING DESCRIPTION
DL1 Yellow ACT
CAN communication activity: normally ashing. Problems on CAN
bus If o󰀨 or on steady
DL2 Red ERR
Error status, normally o󰀨. Flashing upon startup, the number of
ashes represents the FW version. When ERR is on the number of
ashes from CPU LED represents the error code.
DL3 Green CPU
Normally ashing at 1Hz (10Hz during column movement or x-ray
emission). When ERR is on the number of ashes from CPU LED
represents the error code.
DL4 Yellow UP
Normally o󰀨, if on the upper column endpoint has been reached.
Always on if photocell damaged or disconnected.
DL5 Yellow DN
Normally o󰀨, if on the upper column endpoint has been reached.
Always on if photocell damaged or disconnected.
DL6 Red STOP
Normally o󰀨, if on the anti-pich microswitch has been pushed. Always
on if microswitch damaged or disconnected.
DL8 Yellow VAC
On when mains power supply is on. O󰀨 during stand by or in case of
issues with power amplier on the board.
DL9 Yellow VDC
On when 395V are present on power amplier. O󰀨 when in stand-by
or in case of issues with the power amplier.
DL10 Green -5VA Analog -5.3V present, normally on
DL11 Green +5VA Analog +5.3V present, normally on
DL12 Green SW On if switch GBIT power supply present
DL13 Green 18V 18V driver tension present, normally on
DL14 Green 12V 12V driver tension present, normally on
DL15 Green 5V 5V CPU tension present, normally on
DL16 Green 12V 12V for x-ray button, emergency button and interlock, normally on.
