14
1273mm
1 2
3
4
220kg220kg
M8M8
x6x6
MAX
30mm
D
B
A
C
5
20mm
M8M8
x6x6
M8M8
x4x4
hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL
EN
DEVICE INSTALLATION AND CALIBRATION » Assembly instructions
4.1.4 WALL-MOUNTED COLUMN
Not included
Not
included
Included
