hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL

DEVICE INSTALLATION AND CALIBRATION » Assembly instructions

ONLY IF CEPH ARM

IS PRESENT

Put the screws in place

before xing the column to

the wall (do not tighten)

See “Screw kit”, section

“Cinematic group installation”

Tighten
