DEVICE INSTALLATION AND CALIBRATION » Assembly instructions
4.1.7 CHECK DURING THE ASSEMBLING
PREINSTALLATION CHECK RESULT OK
Intact external package

Check compliance of delivery documents

Check ID label/package labels match

Check place of installation and supplies*

POWER SUPPLY CHECK
Connection of power and earth leads

Power supply voltage

Operation of main switch

Check presence of power mains protection

ANTI-ENTRAPMENT SAFETY DEVICE CHECKS
Anti-entrapment safety microswitch*

MECHANICAL CHECKS
Balance of pantograph arm*

Proper attachment and good condition of dental unit casing

DEVICE CHECK AND CALIBRATION
Software installation and conguration

Control panel functions

Collimator setting

INSTRUMENT CHECK AND CALIBRATION
Curing lamp check*

Camera functions and image quality check*

MULTIMEDIA
Power on and monitor functions*

Installation carried out in accordance with local law

Check presence of Quick Guide

* if applicable
4.1.8 CHECKING AFTER MECHANICAL INSTALLATION
After mechanical installation, ensure to check the following points:
1) that the column has no clearance/end oat relative to the fastening system used (stand or wall-mount) or relative to
the metal base installed on the column. If this is not true, contact the manufacturer.
2) that the cephalometry arm (if any) is assembled with the 2 support pins and that the retaining screws are duly
tightened; make sure there is no clearance or end oat.
