CONTROL PANELS AND DISPLAY SYMBOLS
5. CONTROL PANELS AND DISPLAY SYMBOLS
5.1 CONSOLE ONBOARD THE MACHINE
RESET
COLUMN UPWARD
MOVEMENT
COLUMN
DOWNWARD
MOVEMENT
Canine cusp or condyle
VERTICAL LASER POSITIONING (+)
to frame the patient
Canine cusp or condyle
VERTICAL LASER POSITIONING (-)
to frame the patient
