hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL
EN
DEVICE INSTALLATION AND CALIBRATION » Assembly instructions
4.1.5 CINEMATIC GROUP INSTALLATION
Screw kit
# DESCRIPTION Q.TY
A
SCREW TCEI M8x20 12.9 12 / 14
B
ELAS GROWER WASHER FOR M8 15 / 17
C
SCREW TE M8X20 INOX 2
D
SCREW TCEI M8X30 8.8 5
E
SCREW TPSEI M6X16 10.9 4
F
SCREW TCEI M5X16 8.8 2
G
WASHER 8.4X17 S 1.6 R40 2
