CEPH Sensor interface

hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL

CIRCUIT BOARDS

7.7 CEPH SENSOR INTERFACE (97661912)

7.7.1 CONNECTOR LIST

CONNECTOR DESCRIPTION

K1 Synchronization signals from LOGIC

K2 Connector for switch GBIT
