CIRCUIT BOARDS
7.4.1 CONNECTOR LIST
CONNECTOR DESCRIPTION
K1 24V/48V power supply from LOGIC
K2 Revolver motor
K5/K6 Revolver limit switch
K13 CAN towards POWER
K14 CAN towards LOGIC
7.4.2 DIAGNOSTIC LEDS
NAME COLOUR SCREEN PRINTING DESCRIPTION
DL41 Red ERR ON in error condition
DL42 Green CPU Flashing if CPU is OK
DL44 Yellow ACT Flashing if CAN communication is OK
DL45 Green ENBX X axis motor (ON if active)
DL47 Green ENB ON if enabling from LOGIC present
DL48 AUX Not used
DL49 Green OUT On
DL50 DRV Not used
DL51 Green 24V On it 24V power supply present
DL52 Green 5.0V On it 5.0V power supply present
DL53 Green 3.3V On it 3.3V power supply present
DL54 Green 48V On it 48V power supply present
DL55 Green DL55 ON if X axis fuse OK
DL56 Green MINX PAN limit switch (ON if darkened)
DL57 Green MAXX CEPH limit switch (ON if darkened)
