hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL
EN
CIRCUIT BOARDS
7.2.1 CONNECTOR LIST
CONNECTOR DESCRIPTION
K1 Power supply input from POWER board
K2 Collimator motor
K3 Power supply and sync signal PAN/3D sensor
K4 CAN towards POWER connection (only if BRUSHDC is present)
K5 Collimator photocell
K8 Y axis motor
K9 Y axis photocell
K10 Ethernet 100Mb to PC
K13 CAN towards POWER or BRUSHDC
K14 R axis motor
K15 R axis photocell
K16 Keyboard signals connector
K20 CEPH motor
K22 CEPH limit switch
K23 / K26 Monobloc lasers
K24 Chin rest lasers
K36 CEPH sensor synchronization/power supply
K39 Myray logo backlight power supply
K41 Chinrest microswitch
K42 Power supply towards BRUSHDC
K43 / K44 CEPH keyboard
7.2.2 DIAGNOSTIC LEDS
NAME COLOUR SCREEN PRINTING DESCRIPTION
DL1 Yellow ACT
CAN activity. Normally on ashing. On steady or o in case of CAN
error condition.
DL2 Red ERR
Error status, normally o. Flashing upon startup, the number of
ashes represents the FW version. When ERR is on the number of
ashes from CPU LED represents the error code.
DL3 Green CPU
Normally ashing at 1Hz. When ERR is on the number of ashes
from CPU LED represents the error code.
DL4 Yellow MOT. ENB Motors enabled, normally on
DL5 Green SYNC PAN Logic-PAN sensor sync signal
DL7 Green X MOT
On if X motor is active. If ashing the motor is in error (disconnected,
short-circuit, overheating, broken driver)
DL8 Green Y MOT
On if Y motor is active. If ashing the motor is in error (disconnected,
short-circuit, overheating, broken driver)
DL9 Green H MOT
On if H motor is active. If ashing the motor is in error (disconnected,
short-circuit, overheating, broken driver)
DL10 Green R MOT
On if R motor is active. If ashing the motor is in error (disconnected,
short-circuit, overheating, broken driver)
DL11 Green PROG FPGA on, normally ashing (3Hz)
DL12 Green RUN FPGA programmed, normally on
DL13 Green SYNC Synchronization 3D pulses (from POWER)
DL14 Green ENABLE ON if POWER enabled
