hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL
EN
CIRCUIT BOARDS
DL15 ACK Not used
DL16 Yellow XRAY
HW-Rays emission signal from POWER board, normally o󰀨 (On
during ray emission)
DL18 Yellow ACT LAN activity LED. Normally ashing.
DL19 Green LINK LAN connection estabilished. Normally on.
DL22 Green 3.3V 3.3V CPU tension present, normally on
DL23 Green 24V 24V tension present, normally on
DL24 Green 5.0V 5V CPU tension present, normally on
DL25 Green 1.2V 1.2V CPU tension present, normally on
DL29 Green DL29 ON if CEPH axis fuse OK
DL30 Green DL30 CEPH photocell. On if photocell is obscured or disconnected/broken.
DL32 Green DL32 ON if R axis fuse OK
DL33 Green DL33 If ON, R-axis photocell obscured or disconnected
DL35 Green DL35 ON if collomator fuse OK
DL36 Green DL36
Collimator photocell. On if photocell is obscured or disconnected/
broken
DL38 Green DL38 ON if Y axis fuse OK
DL39 Green DL39 If ON, Y-axis photocell obscured or disconnected
DL41 Green SYNC CEPH LOGIC-CEPH sensor synchronization signal
DL43 Green PAN IN
PAN sensor present, normally o󰀨. On if broken cable or PAN sensor
removed
DL44 Green CEPH IN
CEPH sensor present, normally o󰀨. On if broken cable or CEPH
sensor removed
DL46 Green PAN ON
48V PAN Sensor power supply ok. Normally on. O󰀨 during standby
or in error condition on sensor or interface board
DL47 Green CEPH ON
48V CEPH Sensor power supply ok. Normally on. O󰀨 during standby
or in error condition on sensor or interface board
DL49 Green 48V
48V Sensor power supply ok. Normally on. O󰀨 during standby or in
error condition on sensor or interface board
DL53 Green CHIN-L OFF if chinrest not present or chinrest in left position
DL54 Green CHIN-R OFF if chinrest not present or chinrest in right position
DL56 AUX2 Not used
DL57 Green AUX1 ON if BRUSHDC enabled
