Myray hyperion X5 3D CEPH - Connector List

202
SYNC-
SYNC+
EXP_OK-
EXP_OK+ ENB+
ENB-
K3
K1
DL1
DL3
DL2
3 2
1
5
GND GND VCC / VDD
VCC / VDD
K2
1
2
3 8
6 7 10
LOGIC K3
3D PANEL 3D PANEL
hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL
EN
CIRCUIT BOARDS
7.8.1 CONNECTOR LIST
CONNECTOR DESCRIPTION
K1 Synchronization signals from LOGIC
K2 Power supply towards panel
K3 Synchronization signals towards panel
