hyperion X5 3D CEPH/CEPH Ready - TECHNICAL MANUAL

DEVICE INSTALLATION AND CALIBRATION » Cover installation

Connect:

K1 / K11 ► Logic board

K12 ► Ear guides potentiometer

K13 ► Nasion potentiometer

K14 ► Cephalostat drum sensors

(see section “Circuit boards”)
