Nabco GT20 Wire And Programming Manual

24 of 43
GT20 Wire and Programming Manual www.NabcoEntrances.com
P/N C-00140 Rev 5-7-18
Note: Width and Weight Values are necessary in order to adjust for Low Energy Standards.
15. Briey push down on the Joysck to (OK) selecon.
Width
48 in
16. Move the Joysck to the Right or to the Le to select between 30 inches and 63 inches.
17. Briey push down on the Joysck to (OK) selecon.
Weight
200 lbs
18. Move the Joysck to the Right or to the Le to select between 100 pounds and 550 pounds.
a. Weight and Width values adjust for Low Energy Doors.
19. Briey push down on the Joysck to (OK) selecon.
20. Move the Joysck Down to unl the Element Vo is displayed.
Vo
9
21. Vo is the opening speed of the door. Default is (6). Briey push down on the Joysck. The Value will start to blink on the
lower half of the screen.
22. Move the Joysck to the Right or to the Le to select(1) of the following Values: 0...14
23. Briey push down on the Joysck to (OK) selecon.
24. Move the Joysck Down to unl the Element Vc is displayed.
Vc
9
25. Vc is the closing speed of the door. Default is (4). Briey push down on the Joysck. The Value will start to blink on the lower
half of the screen.
26. Move the Joysck to the Right or to the Le to select(1) of the following Values: 0...14
27. Move the Joysck Down to unl the Element Inverse OFF is displayed.
Invers
OFF
28. Inverse is the parameter that communicates to the Control that the installaon is a Spring Open Power Close type. Default is
OFF. Briey push down on the Joysck. The Value will start to blink on the lower half of the screen.
29. Move the Joysck to the Right or to the Le to select(1) of the following Values ON or OFF.
30. Briey push down on the Joysck to (OK) selecon. Move the Joysck Down unl the Element TEACH is displayed.
TEACH
Clear the area of any persons or objects in the path of moving Door Panel, in order to avoid
injuries or damages
31. The Control needs to run an uninterrupted open/close to learn the open and closed posion ang the other parameters.
Ensure the Door Panel is fully closed.
32. Briey push down on the Joysck. The Element Teach OK? will be displayed.
TEACH
ok?
33. Briey push down on the Joysck to (OK) selecon.
a. The setup procedure (Teach) will begin.
b. The GT20 Control will start to beep with each second it takes for the Setup Procedure to complete the programming
process (9 - 0).
c. After countdown, the Door Panel will OPEN to the (Ao) Open Position or to the Open Door Stop position (whichever
WARNING
