4.4 Change of the Network Environment
4-23
4.4.2 Resetting of Scanlist
If changing the IP address in “4.4.1 Resetting of the fieldbus and EtherNet/IP (master and slave)”, it is
necessary to make a resetting of network.
Resetting of network by RSLinx Classic
1
Set ”Execute Mode” for EtherNet/IP (master) to “Configuration” and write in the
fieldbus setting to initialize the module.
It is necessary to detect all the masters and slaves in the network by RSLinx Classic.
To do this, the robot controller to be used in the Ethernet IP network has to be done
with resetting of the master (”Execute Mode”：Setting) and slave first, and started up
connected to the Ethernet/IP network.
2
Connect the setting PC to the hub in the EtherNet/IP network.
3
Start up RSLinx Classic using the setting PC.
To Next Page
