4.4 Change of the Network Environment
4-27
7
Press the menu “Network->Download to Network”.
Download the detail of resetting to the network, and apply it.
8
Right-click the master, and press “Download to Device”.
Download the details of resetting of the “Scanlist Configuration” to the master module.
Thus, resetting of the Scanlist by RSNetWorx for EtherNet/IP is completed. Setting the ”Execute Mode” of the
master of the robot controller to ”Run”, EtherNet/IP communication is going to be active.
If resetting operation is properly done with the ”Execute Mode” of the master set to ”Run", the fieldbus monitor
shows the EIP MASTER and EIP SLAVE specified as "Device began scanned".
