NAiS FP Series User Manual

FPΣ
High-speed Counter and Pulse Output Functions
6-48
Absolute value positioning operation
When X1 is turned on, pulses are output from CW output “Y0” or CCW output “Y1” of
specified channel CH0. If the current value at that point is larger than “22,000”, the
pulses are output from Y1, and if the value is smaller than “22,000”, the pulses are
output from Y2.
Y1
Y0
0 V (24 V DC)
X8
(10,000)
Pulse output CW
Pulse output CCW
Motor driver
(- side)
Motor
(+ side)
Start input
22,000 (30,000)
Regardless of the current value, its movement is towards position “22,000.”
Figure 112: FPΣ Sample program - absolute value positioning operation
