FPΣ
Communication Function 1 Computer Link
8-12
Setting of system register
To carry out 1:1 communication using a computer link, the system registers should be
set as shown below.
Settings when using the COM. 1 port
No. Name Set value
No. 410 Unit No. for COM.1 port 1
No. 412 Communication mode for COM.1 port Computer link
No. 413 Communication format for COM.1 port Character bit: 8 bits....
Parity check: Odd.....
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415 Baud rate setting for COM.1 port 9600 bps to 115200 bps
Settings when using the COM. 2 port
No. Name Set value
No. 411 Unit No. for COM.2 port 1
No. 412 Communication mode for COM.2 port Computer link
No. 414 Communication format for COM.2 port Character bit: 8 bits....
Parity check: Odd.....
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415 Baud rate setting for COM.2 port 9600 bps to 115200 bps
The communication format and baud rate (transmission speed) should be set to match
the connected computer.
