NAiS FP Series User Manual

FPΣ
9.3 Connection Example with External Devices
9-17
Setting of system register
In the default settings, the COM. port is set to the computer link mode. To carry out
1 :1 communication using general-purpose serial communication, the system registers
should be set as shown below.
Communication format setting for FPΣ
• Settings when using the COM. 1 port
No. Name Set value
No. 412
Communication mode General communication
No. 413
Communication format Character bit: 8 bits....
Parity: Odd..........
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415
Baud rate 9600 bps
No. 416
Starting address for data received DT200
No. 417
Buffer capacity setting for data received 100 byte
• Settings when using the COM. 2 port
No. Name Set value
No. 412
Communication mode General communication
No. 414
Communication format Character bit: 8 bits....
Parity: Odd..........
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415
Baud rate 9600 bps
No. 418
Starting address for data received DT200
No. 419
Buffer capacity setting for data received 100 byte
