NAiS FP Series User Manual

FPΣ
Communication Function 2 General-purpose Serial Communication
9-18
Communication format setting for Micro-Imagechecker
To set the communication mode and transmission format settings for the Micro-
Imagechecker, select “5: Communication” under “5: ENVIRONMENT” on the main
menu, and set the following items.
No. Name Set value
No. 51
Communication mode Normal Mode
No. 52
RS232C Baud rate 9600 bps...........
Length 8.............
Stop bit 1............
Parity Odd..............
Flow Control None........
Serial communication setting for Micro-Imagechecker
To enter settings relating to serial communication for the Micro-Imagechecker, select
“53: Serial Output” under “5: Communication” on “5: ENVIRONMENT” of the main
menu, and set the following items.
No. Name Set value
No. 53
Serial Output Output 5 Column..............
Invalid Digit Repl. 0..........
Read End None...........
Process End None.........
Numerical Calculation Output.
Judgment Output...........
- If “Del” is specified for the invalid processing parameter, zero suppression
processing will be carried out on the output data, and the output format will be
changed. Always make sure “Repl. 0” is specified.
- When outputting data to an external device, numerical calculation is required, so
“Out” should be specified for the “Numerical calculation” parameter.
- When the above settings are specified, data with the contents shown below will
be output from the Micro-Imagechecker.
Tip
C
R
1012345
Terminator (End code)
Results of numerical calculation No.1
Judgment output No.2 0=NG
Judgment output No.1 1=OK
