NAiS FP Series User Manual

FPΣ
9.3 Connection Example with External Devices
9-19
Connection example with Micro-Imagechecker “A200/A100”
• When using the 1-channel RS232C type of communication cassette
FPΣ side (5-pin)
Signal name Abbr.
SD
RD
RS
CS
SG
Transmitted Data
Received Data
Request to Send
Clear to Send
Signal Ground
SD
RD
RS
CS
SG
Micro-Imagechecker side
Symbol
FG
SD
RD
RS
CS
(Not used)
SG
CD
ER
Pin No.
1
2
3
4
5
6
7
8
9
Pin name
Figure 182: FPΣ Connection example with micro-imagechecker 1
• When using the 2-channel RS232C type of communication cassette
FPΣ side (5-pin)
Symbol
FG
SD
RD
RS
CS
SG
CD
ER
Pin No.
1
2
3
4
5
6
7
8
9
(To other device)
Micro-Imagecheckerside
Pin name Signal name Abbr.
S1
R1
S2
R2
SG
Transmitted Data 1
Received Data 1
Transmitted Data 2
Received Data 2
Signal Ground
SD
RD
SD
RD
SG
(Not used)
Figure 183: FPΣ Connection example with micro-imagechecker 2
