FPΣ
9.3 Connection Example with External Devices
9-23
Setting of system register
In the default settings, the COM. port is set to the computer link mode. To carry out
1 :1 communication using general-purpose serial communication, the system registers
should be set as shown below.
Communication format setting for FPΣ
• Settings when using the COM. 1 port
No. Name Set value
No. 412 Communication mode General communication
No. 413 Communication format Character bit: 8 bits....
Parity: Odd..........
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415 Baud rate setting 19200 bps
No. 416 Starting address for data received DT200
No. 417 Buffer capacity setting for data received 100 byte
• Settings when using the COM. 2 port
No. Name Set value
No. 412 Communication mode General communication
No. 414 Communication format Character bit: 8 bits....
Parity: Odd..........
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 415 Baud rate setting 19200 bps
No. 418 Starting address for data received DT200
No. 419 Buffer capacity setting for data received 100 byte
Communication format setting for FP series PLC (FP0, FP1)
No. Name Set value
No. 412 Communication mode for COM. port Computer link
No. 413 Communication format for COM. port Character bit: 8 bits....
Parity: Odd..........
Stop bit: 1 bit.........
Terminator: CR......
Header: STX not exist.........
No. 414 Baud rate for COM. port 19200 bps
To Next Page
