NAiS FP Series User Manual

FPΣ
Specifications
13 - 4
Weight
Unit type Part No. Weight
FPΣ control unit FPG-C32T/C32T2 Approx. 120 g/4.24 oz
FPG-C24R2 Approx. 140 g/4.94 oz
FPΣ expansion unit FPG-XY64D2T Approx. 100 g/3.53 oz
FP0 expansion unit FPG-E8X Approx. 65 g/2.29 oz
FPG-E8R/E8YR Approx. 90 g/3.17 oz
FPG-E8YT/E8YP Approx. 65 g/2.29 oz
FPG-E16R Approx. 105 g/3.70 oz
FPG-E16T/E16P/E16X/E16YT/E16YP Approx. 70 g/2.47 oz
FPG-E32T/E32P Approx. 85 g/3.00 oz
Unit’s current consumption table
Type of unit
Control unit
current
consumption
Expansion unit
current
consumption
Input circuit
current
consumption
Output circuit
current
consumption
This is the cur-
rent consumed
from the control
unitpower supply
connector. If ex-
pansion units or
intelligent units
are added, the
current is in-
creased by the
value indicated
below.
This is the cur-
rent consumed
from the expan-
sion unit power
supplyconnector.
If a unit is not
listed below, it
means that it has
no power supply
connector.
This is the cur-
rent consumed
by the input cir-
cuits of the vari-
ous units. This
value indicates
the current that
flows into the in-
put circuit. “n” in-
dicates the num-
ber of points that
are on.
This is the cur-
rent consumed
by the output cir-
cuits of the vari-
ous units. This
value indicates
the current used
to drive the out-
put circuits. “n”
indicates the
number of points
that are on. This
value does not in-
clude the load
current value.
FPΣ con-
tl
it
FPG-C32T 90 mA or less — 77.2 mA or less 70 mA or less
trol unit
FPG-C32T2 90 mA or less — 77.2 mA or less 70 mA or less
FPG-C24R2 160 mA or less — 77.2 mA or less —
FPΣ expan-
sion unit
FPG-XY64D2T 35 mA or less — 3.5 x n mA or less 15 mA or less
FP0 expan-
i
it
FP0-E8X 10 mA or less — 4.3 x n mA or less —
p
sion unit
FP0-E8R 15 mA or less 50 mA or less 4.3 x n mA or less —
FP0-E8YR 10 mA or less 100 mA or less — —
FP0-E8YT 15 mA or less — — 3 x n mA or less
FP0-E16X 20 mA or less — 4.3 x n mA or less —
FP0-E16R 20 mA or less 100 mA or less 4.3 x n mA or less —
FP0-E16T 25 mA or less — 4.3 x n mA or less 3 x n mA or less
FP0-E16YT 25 mA or less — — 3 x n mA or less
FP0-E32T 40 mA or less — 4.3 x n mA or less 3 x n mA or less
FP0 intelli-
t
it
FP0-A21 20 mA or less 100 mA or less — —
gent unit
FP0-A80 20 mA or less 60 mA or less — —
FP0-IOL 30 mA or less 40 mA or less — —
Commu-
nication
cassette
FPG-COM1
FPG-COM2
20 mA or less — — —
cassette
FPG-COM3 25 mA or less — — —
