FPΣ
13.1 Table of Specifications
13 - 5
13.1.2 Performance Specifications
Item Descriptions
FPG-C32T FPG-C32T2 FPG-C24R2
Number of control-
lable I/O points
Control unit 32points (DCinput:
16, Transistor out-
put: 16)
32points (DCinput:
16, Transistor out-
put: 16)
24points (DCinput:
16, Relay output: 8)
When using FP0 expan-
sion units
Max. 128 points (up
to 3 units)
Max. 128 points (up
to 3 units)
Max. 120 points (up
to 3 units) *When
usingtransistorout-
put type expansion
units
When using FPΣ expan-
sion units
Not possible Max. 288points (up
to 4 units)
Max. 280 points (up
to 4 units) *When
usingtransistorout-
put type expansion
units
When using FP0 and
FPΣ expansion units
Max. 384 points (up
to FP0 3 units and
FPΣ 4 units)
Max. 376 points (up
to FP0 3 units and
FPΣ 4 units) *When
usingtransistorout-
put type expansion
units
Programming method/Control method Relay symbol/Cyclic operation
Program memory Built-in Flash ROM (without backup battery)
(By using exclusive instructions it is possible to write and read
data.)
Program capacity 12,000 steps
Number of instruction Basic 85
High-level 220
Operation speed 0.4 µs/step (by basic instruction)
Operation
memory
points
Relay External input relay (X) 512 points
(* Note 7)
1,184 points
(* Note 7)
1,184 points
(* Note 7)
points
External output relay (Y) 512 points
(* Note 7)
1,184 points
(* Note 7)
1,184 points
(* Note 7)
Internal relay (R) 1,568 points (R0 to R97F) (* Note 1)
Timer/Counter (T/C) 1,024 points (* Note 1 and 2) (for initial setting, Timer: 1,008
points (T0 to T1007), Counter: 16 points (C1008 to C1023)
Timer: Can count up to (in units of 1 ms, 10 ms, 100 ms, or 1
s) x 32767.
Counter: Can count up to 1 to 32767.
Link relays (L) 1,024 points (* Note 1)
Memory
area
Data register (DT) 32,765 words (DT0 to DT32764) (* Note 1)
area
Link data register (LD) 128 words (* Note 1)
Index register (I) 14 words (I0 to ID)
Differential points Unlimited of points
Master control relay points (MCR) 256 points
Number of labels (JP and LOOP) 256 labels
Number of step ladders 1,000 stages
