NAiS FP Series User Manual

FPΣ
Specifications
13 - 58
No. Name Boolean Operand Description Steps
Special instructions
F138 Hours, minutes
and seconds
data to seconds
data
HMSS S, D Converts the hour, minute and second data of (S+1, S)
to seconds data, and the converted data is stored in
(D+1, D).
5
F139 Seconds data to
hours, minutes
and seconds
data
SHMS S, D Converts the seconds data of (S+1, S) to hour, minute
and second data, and the converted data is stored in
(D+1, D).
5
F140 Carry flag set STC Turns on the carry flag (R9009). 1
F141 Carry flag reset CLC Turns off the carry flag (R9009). 1
F143 Partial I/O
update
IORF D1, D2 Updates the I/O from the number specified by “D1” to
the number specified by “D2”.
Only possible for I/O numbers in a range of X0 to XF
and Y0 to YF.
5
F147 Printout PR S, D Converts the ASCII code data in the area starting with
“S” for printing, and outputs it to the word external out-
put relay WY specified by “D”.
5
F148 Self-diagnostic
error set
ERR n
(n: K100
to K299)
Stores the self-diagnostic error number “n” in DT90000
turns R9000 on, and turns on the ERROR/ALARM LED.
3
F149 Message
display
MSG S Displays the character constant of “S” in the connected
programming tool.
13
F157 Time addition CADD S1, S2, D The time after (S2+1, S2) elapses from the time of
(S1+2, S1+1, S1) is stored in (D+2, D+1, D).
9
F158 Time
substruction
CSUB S1, S2, D The time that results from subtracting (S2+1, S2) from
the time (S1+2, S1+1, S1) is stored in (D+2, D+1, D).
9
F159 Serial data
communication
MTRN S, n, D This is used to send data to or receive data from an
external device through the specified COM., RS232C
or RS485 port.
7
BIN arithmetic instruction
F160 Double word
(32-bit) data
square root
DSQR S, D
√(S) → (D)
7
High-speed counter and pulse output control instructions
F0 High-speed
counter and
pulse output
control
MV S,
DT90052
Performs high-speed counter control according to the
control code specified by “S”.
5
F1 Change and
read of the
elapsed
value
DMV S,
DT90044
Transfers (S+1, S) to high-speed counter elapsed val-
ue area (DT90045, DT90044). (* Note)
7
e
l
apse
d
va
l
ue
of high-speed
counter
DT90044,
D
Transfers value in high-speed counter elapsed value
area (DT90045, DT90044) to (D+1, D). (* Note)
7
Note
The elapsed value area varies depending on the channel being
used.
