NAiS FP Series User Manual

FPΣ
Specifications
13 - 62
No. Name Boolean Operand Description Steps
Integer type data processing instructions
F289 16-bit data
zone control
ZONE S1, S2,
S3, D
When S3 < 0, S3 + S1 → D
When S3 = 0, 0 → D
When S3 > 0, S3 + S2 → D
10
F290 32-bit data
zone control
DZONE S1, S2,
S3, D
When (S3+1, S3) < 0,
(S3+1, S3) + (S1+1, S1) → (D+1, D)
When (S3+1, S3) = 0, 0 → (D+1, D)
When (S3+1, S3) > 0,
(S3+1, S3) + (S2+1, S2) → (D+1, D)
16
Floating-point type real number operation instructions
F309 Floating-point
type data move
FMV S, D (S+1, S) → (D+1, D) 8
F310 Floating-point
type data
addition
F+ S1, S2, D ( S1+1, S1) + (S2+1, S2) →(D+1, D) 14
F311 Floating-point
type data
subtraction
F- S1, S2, D ( S1+1, S1) - (S2+1, S2) → (D+1, D) 14
F312 Floating-point
type data
multiplication
F* S1, S2, D ( S1+1, S1) × (S2+1, S2) → (D+1, D) 14
F313 Floating-point
type data
division
F% S1, S2, D ( S1+1, S1) ÷ (S2+1, S2) → (D+1, D) 14
F314 Floating-point
type data sine
operation
SIN S, D SIN (S+1, S) → (D+1, D) 10
F315 Floating-point
type data co-
sine operation
COS S, D COS (S+1, S) → (D+1, D) 10
F316 Floating-point
type datatang-
ent operation
TAN S, D TAN (S+1, S) → (D+1, D) 10
F317 Floating-point
type data arc-
sine operation
ASIN S, D SIN
-1
(S+1, S) → (D+1, D) 10
F318 Floating-point
type data
arccosine
operation
ACOS S, D COS
-1
(S+1, S) → (D+1, D) 10
F319 Floating-point
type data
arctangent
operation
ATAN S, D TAN
-1
(S+1, S) → (D+1, D) 10
F320 Floating-point
type data natu-
ral logarithm
LN S, D LN (S+1, S) → (D+1, D) 10
F321 Floating-point
type data
exponent
EXP S, D EXP (S+1, S) → (D+1, D) 10
