I/O
Allocation
FP0
5-6
Matsushita
Automation
Controls
5.4
Analog
I/O
Unit
5.4
Analog
I/O
Unit
Up
to
three
analog
I/O
units
can
be
added.
The
I/O
allocation
of
analog
I
/O
unit
is
determined
by
the
installation
location.
I/O
number
T
ype
First
expansion
Second
expansion
Third
expansion
A21
Input
channel
0:
16
points
WX2
(X20
to
X2F)
WX4
(X40
to
X4F)
WX6
(X60
to
X6F)
Input
channel
1:
16
points
WX3
(X30
to
X3F)
WX5
(X50
to
X5F)
WX7
(X70
to
X7F)
Output:
16
points
WY2
(Y20
to
Y2F)
WY4
(Y40
to
Y4F)
WY6
(Y60
to
Y6F)
Third
expansion
Second
expansion
First
expansion
Control
unit
99
101
