Control Units
FP0
2-7
Matsushita Automation Controls
2.2 Specifications
2.2 Specifications
2.2.1 General Specifications
Item Description
Rated operating voltage
24 V DC
Operating voltage range
21.6 V to 26.4 V DC
Rated current
consumption
300 mA or less
(
*
section 2.2.1.2
)
Allowed C10/C14
5 ms at 21.6 V, 10 ms at 24 V
momentary
power off time
C16/C32
10 ms at 21.6 V, 10 ms at 24 V
Ambient temperature
0
q
C to +55
q
C/32
q
F to +131
q
F
Storage temperature
-20
q
C to +70
q
C/- 4
q
F to +158
q
F
Ambient humidity
30 % to 85 % RH (non-condensing)
Storage humidity
30 % to 85 % RH (non-condensing)
Breakdown voltage
500 V AC for 1 minute between I/O terminal and power
supply/ground terminal
1500 V AC for 1 minute between I/O terminal and power
supply/ground terminal (relay output type only)
Insulation resistance
min. 100 M
Ω
(measured with a 500 V DC megger)
between I/O terminal and ground terminal
Vibration resistance
10 Hz to 55 Hz, 1 cycle/min: double amplitude of 0.75 mm/
0.030 in., 10 min on 3 axes
Shock resistance
Shock of 98 m/s
2
or more, 4 times on 3 axes
Noise immunity
1,000 Vp-p with pulse widths 50 ns and 1
P
s (based on
in-house measurements)
Operating condition
Free from corrosive gases and excessive dust
2.2.1.1
Weight
Type Weight
C10RS/C10CRS/C10RM/C10CRM
approx. 100 g/3.53 oz
C14RS/C14CRS/C14RM/C14CRM
approx. 105 g/3.70 oz
C16T/C16CT/C16P/C16CP
approx. 85 g/3.00 oz
C32T/C32CT/C32P/C32CP
approx. 115 g/4.06 oz
E8RS/E8RM
approx. 90 g/3.17 oz
E8X/E8YT/E8YP
approx. 65 g/2.29 oz
E16RS/E16RM
approx. 105 g/3.70 oz
E16T/E16P/E16X/E16YT/E16YP
approx. 70 g/2.47 oz
E32T/E32P
approx. 85 g/3.00 oz
