NAiS FP0-C32T User Manual

Control Units
FP0
2-8
Matsushita Automation Controls
2.2 Specifications
2.2.1.2
Current Consumed by the Control Unit
The current consumed at the power supply connector of the control unit is the sum of
the current consumed by of the various units being used.
Type
Current consumption
(at 24 V DC)
Control unit C10RS, C10CRS, C10RM, C10CRM
100 mA or less
C14RS, C14CRS, C14RM, C14CRM
100 mA or less
C16T, C16CT, C16P, C16CP
40 mA or less
C32T, C32CT, C32P, C32CP
60 mA or less
Expansion I/O E8X
10 mA or less
p
/
unit
E8YT, E8YP
15 mA or less
E8RS, E8RM, E16RS, E16RM, E16X
20 mA or less
E16YT, E16YP, E16T, E16P
25 mA or less
E32T, E32P
40 mA or less
Analog I/O unit A21
20 mA or less
FP Programmer
II
Ver. 2 (AFP1114V2)
50 mA or less
C-NET adapter S2 type (AFP15402)
50 mA or less
Current consumed when the unit requires an external power supply
With a relay output type of expansion I/O unit and an analog I/O unit, it is necessary to
provide a power supply to drive internal circuits.
Type
Current consumption
(at 24 V DC)
Expansion I/O E8RS, E8RM
50 mA
p
/
unit
E16RS, E16RM
100 mA
Analog I/O unit A21
100 mA
