NAiS FP0-C32T User Manual

Expansion I/O Units
FP0
3-6
Matsushita Automation Controls
3.2 Specifications
3.2 Specifications
3.2.1 General Specifications
For more details on the general specifications, refer to section 2.2.1.
3.2.2 Input Specifications
Item Description
Insulation method
optical coupler
Rated input voltage
24 V DC
Rated input current
approx. 4.3 mA (at 24 V DC)
Input impedance
approx. 5.6 k
Ω
Operating voltage range
21.6 to 26.4 V DC
Input points
per common
E8RS,
E8RM
4 points/common
pe
co o
(
*
Note)
E16RS,
E16RM,
E16T, E16P,
E8X
8 points/common
E32T, E32P,
E16X
16 points/common
ON voltage/ON current
19.2 V or less/3 mA or less
OFF voltage/OFF current
2.4 V or more/1 mA or more
Response time
(at
24
V
DC
and
OFF
l
ON
2 ms or less
(at 24 V DC and
25
q
C/66
q
F)
ON
l
OFF
the same as above
Operating mode indicator
LED
.
Note
Either positive or negative polarity is possible for the input
voltage supply.
