NAiS FP0-C32T User Manual

Expansion I/O Units
FP0
3-5
Matsushita Automation Controls
3.1 Parts and Terminology
1 4
Power supply connector
Supply 24 V DC. It is connected using the power supply cable (AFP0581) that comes with the unit.
2
Input terminal (9-pin)
3
Output terminal (9-pin)
4
The input and output terminals (
2
and
3
) use a terminal block socket made by Phoenix Contact Co.
(product number: 1840434) (
*
section 7.6).
5
Input connector (9-pin)
6
Output connector (9-pin)
The input and output connectors (
5
and
6
) use a connector made by Molex Japan Co. (product
number: 51067-0900) (
*
section 7.7).
7 11
Input connector (10-pin)
8 13
Output connector (10-pin)
9 12
Input connector (10-pin
×
2)
10 14
Output connector (10-pin
×
2)
11 12 13 14
Use a MIL type connector for the input and output connectors (
7
to
14
)(
*
section 7.8).
15 18
Expansion hook
is used to secure expansion units.
16
Expansion connector
connects an expansion unit to the internal circuit of the expansion I/O unit (
*
section 6.1).
17
DIN rail attachment lever
18
allows simple attachment to a DIN rail.
The lever is also used for installation on FP0 slim type mounting plate (AFP0803).
