10. Parts List
No. Name Qty. Type or Rating Part No.
1 Main cabinet 1
2 Rear door 1
3 Top acrylic 1
4 Signboard reflector 1
5 Cushion 2
6 Monitor glass 1
7 Camera bracket 1
8 Steering stay (L) 1
9 Steering stay (R) 1
10 Monitor side bracket (L) 1
11 Door key 1
12 Service plate 1
13 Led tube 600 1
14 LCD bracket
15 Monitor stopper (upper) 1
16 Monitor stopper (lower) 1
17 Ventilation panel 1
18 Monitor side bracket (R) 1
19 Control panel under cover 1
20 Game PC Board 1 SYS ES3 (A) ASSY
21 LCD monitor 1
22 Led bar 600 1
23 POP LED bracket 1
24 Rainbow PC Board 9 SCU02-A
25 Corner cover (M) 2
26 NA-JV (M) PC board 1 NA-JV (M) PCB (ROM) Assy
27 Amp PC board 1 V389 C2-IS AMP PCB Assy
28 Steering PC board 1 STR4 (M) PCB (ROM) Assy
29 Coin counter 2
30 Switching regulator (12 V) 1 RS-150-12
31 Switch (toggle) 1
32 Switch (push) 1 PBS-10B
33 Switch (push) 1 PBS-10B
34 Switch (toggle)
1
36 Current fuse (5A SB) 2
37 Caster (adjustable) 4
38 Adjustment bolt 4
XMK3-734-951
XMK3-734-952
XMK3-734-950
XMK3-735-035
XMK3-735-022
XMK3-735-023
XMK3-735-029
XMK3-733-330
XMK3-735-045
XMK3-307-781
XMK3-735-018
XMK3-735-020
XMK3-735-027
XMK3-734-994
XMK3-734-995
XMK3-734-985
XMK3-734-984
XMK3-734-983
XMK3-734-982
XMK3-735-016
XMK3-735-016
XMK3-735-003
XMK3-735-015
1
XMK3-734-957
XMK3-734-958
XMK3-734-964
XMK3-735-030
XMK3-734-969
ーーーー
ーーーー
ーーーー
ーーーー
ーーーー
XMK3-734-977
