96
— Must be performed by a technician —
(1) Removing and Installing the Pedal Assembly
to the electronic circuits, be sure to turn off the power switch before starting work.
Disconnect the connector.
After completing the replacement, be sure to check the operation and initialize.
Connector
Pedal assembly
Torx bolt (M5 x 25)
Torx bolt (M5 x 25)
Pedal assembly
To Next Page
