101
Test Mode
Troubleshooting
— Must be performed by a technician —
(3) Replacing the Rainbow PC Board (seat)
damage to the electronic circuits, be sure to turn off the power switch before
starting work.
corresponds to the malfunction location.
The PC board is sensitive to static electricity. If a person handles a PC board
while charged with static electricity, the parts on the PC board may be damaged.
Before handling the PC board, discharge the static electricity from your body; for
example, by touching the surface of grounded metal.
Connector
Torx bolt (M5 x 25)
Tail Lamp Panel
To Next Page
