87
Test Mode
Troubleshooting
— Must be performed by a technician —
damage to the electronic circuits, be sure to turn off the power switch before
starting work.
The PC board is sensitive to static electricity. If a person handles a PC board
while charged with static electricity, the parts on the PC board may be damaged.
Before handling the PC board, discharge the static electricity from your body; for
example, by touching the surface of grounded metal.
Torx bolt (M5 x 25)
Top acrylic
Phillips pan head screw
(with flat and spring washers)
(M4 x 8)
Phillips pan head screw
(with flat and spring washers)
(M4 x 8)
Connector
LED bar (L)
To Next Page
