Test Mode
Troubleshooting
— Must be performed by a technician —
damage to the electronic circuits, be sure to turn off the power switch before
starting work.
After completing the replacement, be sure to check the operation.
Monitor side BK (L)
Phillips pan head screw
(with spring washer) (M3 x 6)
Rainbow
PC Board
Connector
Monitor side LED BK (L)
Countersunk
washer nut (M4)
To Next Page
