10. Parts List
10-5 Pedal Assembly
No. Name Qty. Type or Rating Part No.
1 Pedal A 1
2 Pedal B 1
3 Cushion 4
4 Spring A 2
5 Spring B 1
6 POTENTIOMETOR 1 F24KN5-20 B1Kb7-B0 L20FC*8.5 (0)
7 SENSOR 1 KI1300
XMK3-727-987
XMK3-727-986
XMK3-000-677
XMK3-008-076
XMK3-727-998
XMK3-727-999
XMK3-727-994
