— Must be performed by a technician —
Inside the Front Assembly Rear
Tap-in pan head screw
OG WH
GN/YE
To avoid damaging the electronic circuits, make sure that the connector direction
is correct when connecting the connectors.
The PC board is vulnerable to static electricity. If a person handles a PC board
while charged with static electricity, the parts on the PC board may be damaged.
Before handling the PC board, discharge the static electricity from your body; for
example, by touching the surface of grounded metal.
When connecting the ring terminals, check the harness colors and contact
conditions carefully to avoid damaging the electronic circuits.
to the electronic circuits, be sure to turn off the power switch before starting work.
terminal connection locations.
