89
Test Mode
Troubleshooting
— Must be performed by a technician —
Board.
When sending a part for repair (Game PC Board), wrap it in sponge or bubble
wrap before packing it in a cardboard box. Make sure that the box is not
exposed to outside pressure.
After completing the replacement, be sure to check the operation and initialize.
Game PC Board
Rack base
Phillips pan head screw
(With flat and spring washers) (M4 x 14)
Phillips pan head screw
(With flat and spring washers)
(M4 x 14)
To Next Page
